Conductor	7×72/0.08mm Bare stranded copper
Insulation material	Special high intensity TPE mixture
Insulation diameter	2.0mm Nom
Insulating color	Black [1~3],yellow/green Black insulation with white number
Cable assembly	Filled with cotton yarn, and wrapped with non-woven fabric
Shielded	Tinned copper braid，coverage≥85%
Isolation	Non-woven fabric
Jacket material & color	PUR, Black（Matt）
Jacket diameter	7.60±0.3mm
Operation voltage	300/500V
Operation temperature	-25~80℃(Flexible),-40~80℃(Fixed)
Drag chain test	Seed：2m/s，acceleration：20m/s²，distance travelled：1m；≥20 million cycles
Torsion test: angle & frequency	Angle: ±180°, frequency: 60 times per minute, ≥10 million times
Flame resistance	FT2
Dielectric test	2.0 KV/1 minute
Hazardous Substance Free	Accord with RoHS

Application

Industrial robots and ultra-high speed drag chain system applications. Mainly used in the internal wiring of industrial robots, machine tools, industrial automation and other equipment with complex environment and harsh motion, power signal transmission under long-term high-speed motion.
